Dust Chip Extraction Nut

  • Core Components: PLC
  • Product name: CNC Dust Chip Extraction Nut
  • Material: Alloy Steel
  • Package: Plastic Box
  • Color: Black Silver
  • Hardness: HRC44-48
  • Accuracy: 0.003mm-0.005mm
Sign Up To Get 12% Off For Your First Order

Main features

  • It helps remove waste typically but not exclusively when nesting.
  • It replaces the standard nut on your collet chuck with the collet locking into the nut.
  • The vortex created by the nut lifts the waste from the table enabling the overhead dust extraction to remove the waste.
  • With the waste removed your tool life is extended, your cut quality is improved and the working environment is cleaner and healthier.

Application

  • Dust Chip Extraction When Woodworking
序号 编号 型号 外径 内径 高
NO. code Model Outer diameter Inner diameter Height
1 508020 ER20 63 23 40
2 508025 ER25 63 30 36
3 508032 ER32 78 38 40
4 508040 ER40 83 48 40
5 5080257 OZ25 78 45 42

Speed And Feeds

Below you will find downloadable and printer-friendly Speeds & Feeds for this product line. All posted Speed & Feed parameters are suggested starting values that may be increased given optimal setup conditions. If you can’t find the information you’re looking for, Weix Tool has a team of technical experts available to assist you.

Contact Us: [email protected]

Click there to download files
